Simple Colour Organ

Home > Circuits > Light/Laser > Simple Colour Organ

Author	Views	Views Today	Rank	Comments
	140,002	12		11

This is a simple, one lamp colour organ. It is far less complicated then the Three Channel Colour Organ. It is simply a lamp controlled by an SCR. It can be built in a few minutes, and combined with other circuits to make some pretty neat effects.

Schematic

Parts

Part	Total Qty.	Description	Substitutions
R1	1	500 Ohm Pot
T1	1	500 Ohm/500 Ohm Matching Transformer	1K/1K Matching Transformer
SCR1	1	C106Y SCR	106B, Teccor S2003LS1
L1	1	10-100 Watt Lamp
MISC	1	Case, Board, Socket For L1, Line Cord

Notes

L1 can be any 10-100 Watt lamp.

R1 adjusts sensitivity. The greater the resistance, the less sensitive the colour organ becomes.

Since this project is powered by 120 VAC, it must be installed in a case.

You can also use the Teccor S2003LS1 SCR for SCR1. These give better sensitivity and brightness than the C106Y units.

Related Circuits

Comments

Add A Comment

Clair Simple Colour Organ Tuesday, July 19, 2022 12:03:01 PM

in this simple light color organ i noticed a major part mistake, you should use the C106B1, not the C106Y because it only has a maximum rated voltage of 30 volts While the C106B1 is rated for 200 volts

pyromaniac Simple Colour Organ Friday, December 11, 2009 9:03:51 AM

Is there any way to make it run on 220v?

martin Simple Colour Organ Tuesday, December 08, 2009 8:05:23 AM

Srry about a stupid question but where should i get the scr. Can i find it from any electrical machines( Tv, some broken PCs, in coffee machine or something like that). Please reply, im stuck on that. Theres not much info on the web.

martin Simple Colour Organ Thursday, December 03, 2009 2:21:42 PM

Sorry about a stupid question but where would i get the C106Y SCR

anonymous Simple Colour Organ Wednesday, November 26, 2008 8:57:15 AM

What type of mic should be used? Any?? Pre-amp???

paul Simple Colour Organ Monday, August 18, 2008 4:48:47 PM

teh mic connects to the unused side of the matching transformer, as the mic changes the inductive field of the transformer, the secondary coil then changes the bias of the triac...

anonymous Simple Colour Organ Monday, July 09, 2007 3:09:20 AM

How would sound activation be integrated into this circuit? ex. sound in mic = to patterns in lightbulb

OSAMA1 Simple Colour Organ Wednesday, May 30, 2007 4:32:37 AM

VERY GOOD

TheScience Simple Colour Organ Thursday, May 10, 2007 6:49:24 AM

The secret to understanding electronics is to understand each part and what role it plays in the circuit. Of each thing you see in a circuit, ask: "What to I expect to put in and what will this device do with it." If you can answer that, the circuit is self-explanitory. If not, educate yourself. Don't expect everything to be handed to you with a ribbon.

lowlife Simple Colour Organ Friday, May 04, 2007 5:51:23 PM

cool
