Touch Switch

Author	Views	Views Today	Rank	Comments
	147,668	76		49

A touch switch is a switch that is turned on and off by touching a wire contact, instead of flicking a lever like a regular switch. Touch switches have no mechanical parts to wear out, so they last a lot longer than regular switches. Touch switches can be used in places where regular switches would not last, such as wet or very dusty areas.

Schematic

Parts

Part	Total Qty.	Description	Substitutions
C1	1	10uF 16V Electrolytic Capacitor
R1, R2	2	100K 1/4 Watt Resistor
R3	1	10 Meg 1/4 Watt Resistor
U1	1	4011 CMOS NAND Gate IC
MISC	1	Board, Wire, Socket For U1

Notes

The contacts an be made with just two loops of wire close together, or two squares etched close together on a PC board.

When activated, the output of the circuit goes high for about one second. This pulse can be used to drive a relay, transistor, other logic, etc.

You can vary the length of the output pulse by using a smaller or larger capacitor for C1.

Related Circuits

Comments

Add A Comment

jay Touch Switch Tuesday, March 09, 2010 8:00:02 AM

i need help!!!!!! how will be the out put taken and how will be the in put given their is only one out put terminal if i want connect a led how can i connect and a switch needs a input supply where should i give in put can i use ic7400 for nand gate please help me its urgent thank u

anonymous Touch Switch Saturday, February 06, 2010 10:28:44 PM

I need this to work with batteries... 3.7v, 6v, and 7.2v... all pushing up to 2amps. How can I configure this to work with all three situations?

Godofredo Gregorio Jr. Touch Switch Monday, June 15, 2009 11:27:16 PM

It's so useful. We can use it in many different way. It can be a touch switch to a 220volt lamp with a 220volt, 5amp relay connected at the output of the circiut. It's great in everyday use.... JonjonGregorio-Philippines

anonymous Touch Switch Monday, February 16, 2009 11:21:20 AM

what the output is going to be?? can i put an led to know if the circuit is working or not?? does the circuit working by touching wires by fingers or what?? any one knows the answers, please tell me cuz i am doing this device at the moment. thnks alot.

cuan Touch Switch Monday, February 16, 2009 11:08:33 AM

can i make a touch switch using two scr??? if can then how does it work. and the circuit only power by dc voltage so i have a hard time to turn off the scr.. only one touch switch is needed and the touch switch use to turn and off the bulb

anonymous Touch Switch Tuesday, December 23, 2008 10:02:21 AM

What am i going to do inorder to make the touch switch just like any other ordinary switches which "on" state is permanent unless it is turned off???

gardenyu Touch Switch Friday, November 07, 2008 5:17:59 PM

I wonder where can I buy a fairly big touch switch? ( about 1 to 2 inch diameter)?

anonymous Touch Switch Monday, October 27, 2008 3:59:51 AM

i was thinking about adding one of these touch switches to my shaved door handles, so all you do isun lock the car and hit the touch switch . probally mount it behind a window or where the door handle used to be.

jazk Touch Switch Thursday, October 09, 2008 1:56:26 PM

anybody know about this title "touch switch" ...what the function and what use for this...?

Bee Touch switch ....Main supply detection Tuesday, September 16, 2008 11:03:09 AM

Great job and works right away ! I need to get an image of the main supply (220V- 110V 50/60Hz)but do not have an access to the hot wires....just the isolated cable I need to get the Freq (not a Pb) but also the phase (Zero crossing detector) on rising edge.... any idea ?????
