Rain Detector

Author	Views	Views Today	Rank	Comments
	124,964	94		102

This circuit uses a sensor made of a small piece of etched PC board and a simple SCR circuit to detect rain and sound a buzzer. The SCR could also be used to activate a relay, turn on a lamp, or send a signal to a security system.

Schematic

Parts

Part	Total Qty.	Description	Substitutions
R1	1	1K 1/4 W Resistor
R2	1	680 Ohm 1/4 W Resistor
D1	1	1N4001 Silicon Diode
BZ1	1	12V Buzzer
S1	1	SPST Switch
SCR1	1	C106B1 SCR	106CY
SENSOR	1	See Notes
MISC	1	Board, Wire, Case, PC Board (For Sensor)

Notes

The sensor is a small piece of PC board etched to the pattern showen in the schematic. The traces should be very close to each other, but never touching. A large spiral pattern would also work.

Make sure to use a loud buzzer.

Related Circuits

Comments

Add A Comment

anonymous Rain Detector Tuesday, December 01, 2009 3:40:41 AM

i built this project, but the "buzzer" still On after sensor become wet, but after the sensor is dry, the buzzer still active, Why??, I want the sensor to stop the buzzer when dry. thanx

Questioner Rain Detector Saturday, September 05, 2009 2:38:01 PM

How to make the circuit can differentiate between light, moderate and heavy rain? The application is to control speed motor. For example, minimum speed for light rain and maximum speed for heavy rain.

Julian Rain Detector Saturday, May 09, 2009 4:19:17 AM

I've built this but it activates even when i complete the circuit with two people touching hands in series with the detector. Its WAY too sensitive. Is there a resistor change that would make the detector less sensitive? It also doesn't turn off when the contact across the sensor (water or finger) is removed. HELP

anonymous Rain Detector Sunday, March 15, 2009 7:21:58 PM

fantastic i have my own idea for this and let you know when i sort it ;) thanks

M. ASlani Rain Detector Sunday, March 08, 2009 2:24:57 PM

There is a problem with this rain sensor. the rain drops remain on the surface of sensor even when the PCB is installed in 45 degree position. Does somebody suggest any method to solve this problem?
(Editor's notes: Coat with RainX.)

conductivitysensor Rain Detector Wednesday, February 18, 2009 9:30:54 AM

does this pc board works if u plant it in the soil and can detect conductivity if you will water the soil??

siddeswaran Rain Detector Monday, February 16, 2009 2:42:28 AM

when the water falls on the sensor it sense , transfer the information to scr1 and to activity the buzzer

naveed malik Rain Detector Saturday, February 07, 2009 4:10:05 AM

very funny

Tim Hurt Rain Detector Friday, January 16, 2009 5:07:14 PM

Am building a bed-wetting detector for my niece and will use this ckt. Want to use +9 VDC battery so I don't shock baby plus tie a HI intensity flashing LED to pulse the piezo 70 dB buzzer and wake the child. Thanx 4 your ckt design. Will tweak it a bit 4 my purposes & let you know how she works out!

anonymous Rain Detector Tuesday, January 13, 2009 2:55:56 PM

Thanks for posting this plan. Very helpful and clear. I think it may be useful to use something like this large scale, example as toilet water. Maybe large-scaled projects like this don't take so much trouble for all the water we would save.
