Telephone Hold Button

Home > Circuits > Telephone > Telephone Hold Button

Author	Views	Views Today	Rank	Comments
	131,905	10		10

Although a hold feature is standard on most new phones, a lot of us still use the origional bell phones. Those of us that require a hold feature will find this circuit very useful. It is easy to build, and is compact enough to be installed inside the phone with no real problem. It is also powered by the phone line itself, eliminating the need for batteries.

Schematic

Parts

Part	Total Qty.	Description	Substitutions
R1	1	1.5K 1/4 W Resistor
R2	1	1K 1/4W Resistor
D1	1	1N4002 Silicon Diode	1N4003, 1N4004, 1N4005, 1N4006, 1N4007
SCR1	1	C106Y SCR
LED1	1	Red LED	Green LED, Yellow LED
S1	1	Normally Open Push-Button Switch
MISC	1	Wire, Board, Case (If Used)

Notes

To place a call on hold, simply hold down the button while hanging up the phone. To take a call off hold, just pick up the phone, or any extension.

Even though this is a simple circuit, you may have to check with your phone company before use.
